n8n-nodes-aws-sqs-full

Complete AWS SQS integration for n8n workflow automation

A comprehensive AWS SQS community node package for n8n that provides complete queue workflow automation with three essential nodes: Send, Delete, and Trigger operations.

Features

• Send Messages: Send messages to SQS queues with automatic queue discovery
• Delete Messages: Delete messages from SQS queues efficiently
• Trigger Workflows: Monitor queues and trigger workflows when messages arrive
• FIFO Support: Full support for FIFO queues with Message Group ID and Deduplication ID
• Message Attributes: User-friendly interface for custom message attributes
• Native AWS Credentials: Uses n8n's built-in AWS credential system
• Error Handling: Robust error handling with continue-on-fail support
• Production Ready: Optimized for production workloads

Installation

Via n8n Community Nodes (Recommended)

1. Go to Settings → Community Nodes in your n8n instance
2. Click Install and enter: n8n-nodes-aws-sqs-full
3. Click Install and wait for the installation to complete

Via npm

npm install n8n-nodes-aws-sqs-full

Requirements

• n8n version 0.198.0 or higher
• Node.js 16.0.0 or higher
• AWS account with SQS access

Quick Start

AWS Credentials Setup

1. Go to Settings → Credentials in n8n
2. Click Add Credential and select AWS
3. Configure your AWS credentials:
   • Access Key ID: Your AWS access key
   • Secret Access Key: Your AWS secret key
   • Region: Your AWS region (e.g., us-east-1)

Basic Usage

Sending Messages

{
  "queue": "https://sqs.us-east-1.amazonaws.com/123456789012/my-queue.fifo",
  "sendInputData": true,
  "messageGroupId": "order-processing",
  "messageDeduplicationId": "order-123456"
}

Deleting Messages

{
  "queueUrl": "https://sqs.us-east-1.amazonaws.com/123456789012/my-queue",
  "receiptHandle": "AQEBwJnKyrHigUMZj6rYigCgxlaS3SLy0a..."
}

Triggering on Messages

{
  "queueUrl": "https://sqs.us-east-1.amazonaws.com/123456789012/my-queue",
  "pollingInterval": 30,
  "maxMessages": 10,
  "deleteAfterProcessing": true
}

Available Nodes

AWS SQS Send

Send messages to SQS queues with comprehensive configuration options.

Key Parameters:

• Queue selection from dropdown (auto-loaded from AWS)
• Send Input Data option for workflow integration
• Message Attributes with Name/Value/Type interface
• FIFO queue support with Message Group ID and Deduplication ID
• Delay message delivery (0-900 seconds)

AWS SQS Delete

Delete messages from SQS queues after processing.

Key Parameters:

• Queue URL (full SQS queue URL)
• Receipt Handle (from received message)

AWS SQS Trigger

Monitor SQS queues and trigger workflows when messages arrive.

Key Parameters:

• Queue URL for monitoring
• Polling interval (configurable)
• Maximum messages per poll
• Auto-delete after processing option

Use Cases

Order Processing Pipeline

{
  "nodes": [
    {
      "name": "Order Created",
      "type": "n8n-nodes-base.webhook"
    },
    {
      "name": "Send to Queue",
      "type": "n8n-nodes-aws-sqs-full.awsSqsFullSend",
      "parameters": {
        "queue": "https://sqs.us-east-1.amazonaws.com/123456789012/orders.fifo",
        "sendInputData": true,
        "messageGroupId": "orders"
      }
    }
  ]
}

Message Processing Workflow

{
  "nodes": [
    {
      "name": "Receive Message",
      "type": "n8n-nodes-base.awsSqs"
    },
    {
      "name": "Process Message",
      "type": "n8n-nodes-base.function"
    },
    {
      "name": "Delete Message",
      "type": "n8n-nodes-aws-sqs-full.awsSqsFullDelete",
      "parameters": {
        "queueUrl": "{{$node['Receive Message'].json.queueUrl}}",
        "receiptHandle": "{{$node['Receive Message'].json.receiptHandle}}"
      }
    }
  ]
}

AWS IAM Permissions

Your AWS user needs the following permissions:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": [
        "sqs:SendMessage",
        "sqs:DeleteMessage",
        "sqs:ReceiveMessage",
        "sqs:ListQueues",
        "sqs:GetQueueAttributes"
      ],
      "Resource": "arn:aws:sqs:*:*:*"
    }
  ]
}

Configuration

Message Attributes

Use the user-friendly interface to add custom message attributes:

Field	Type	Description
Name	string	Attribute name
Value	string	Attribute value
Type	string	Data type (String, Number, Binary)

FIFO Queues

For FIFO queues, ensure you provide:

• Message Group ID: Required for FIFO queues
• Message Deduplication ID: Optional, auto-generated if not provided

Error Handling

All nodes support n8n's standard error handling:

• Enable "Continue on Fail" to handle errors gracefully
• Use error outputs to build robust workflows
• Monitor execution logs for troubleshooting

Development

Build from Source

# Clone the repository
git clone https://github.com/adejaimejr/n8n-nodes-aws-sqs-full.git

# Install dependencies
npm install

# Build the project
npm run build

# Run tests
npm test

Project Structure

n8n-nodes-aws-sqs-full/
├── nodes/
│   ├── AwsSqsDelete/
│   ├── AwsSqsSend/
│   └── AwsSqsTrigger/
├── dist/
├── package.json
└── README.md

Resources

• AWS SQS Documentation
• n8n Community Nodes
• n8n Documentation
• Community Forum

Support

Need help? Join our community:

• GitHub Issues
• n8n Community Forum

FAQ

Q: Can I use this with FIFO queues?
A: Yes, all nodes work with both Standard and FIFO SQS queues.

Q: How does automatic queue loading work?
A: The Send node automatically loads all queues from your AWS account using configured credentials.

Q: What happens if a message operation fails?
A: The node will return an error, but you can enable "Continue on Fail" to handle this gracefully.

Q: Is there a limit to delay seconds?
A: AWS SQS supports delays from 0 to 900 seconds (15 minutes).

Contributing

We welcome contributions! Please see our Contributing Guide for details.

Found a bug 🐛 or have a feature idea? Create an issue.

License

This project is licensed under the MIT License - see the LICENSE file for details.

About

Created by Adejaime Junior for the n8n community.
