n8n-nodes-picedit

A powerful n8n community node for image processing and generation. Create canvases, add text overlays, and composite images with full binary data support. Built with Sharp.js for high-performance image processing without external dependencies.

🚀 Features

• Canvas Creation: Create blank canvases or use existing images as backgrounds
• Text Overlays: Add customizable text with fonts, colors, rotation, and opacity
• Image Composition: Overlay images with scaling and rotation support
• Binary Data Support: Full integration with n8n's binary data workflow
• Batch Processing: Process multiple text elements from CSV files
• Security: Built-in path validation and security measures
• Pure Node.js: Built with Sharp.js - no Python or external dependencies required
• High Performance: Fast image processing with native Sharp library
• Cross-Platform: Works on Windows, macOS, and Linux
• Unicode Support: Full support for emoji and special characters

📦 Installation

Community Installation

Install via n8n's community nodes feature:

1. Go to Settings > Community Nodes
2. Enter the package name: n8n-nodes-picedit
3. Click Install

Manual Installation

# In your n8n installation directory
npm install n8n-nodes-picedit

Prerequisites

• Node.js 16.10 or higher
• n8n 0.190.0 or higher

No additional dependencies required! The node uses Sharp.js which is automatically installed as a dependency.

🎯 Node Operations

Create Canvas

Create a new image canvas as the foundation for your design.

Options:

• Blank Canvas: Custom dimensions with solid background color
• From Image: Use an existing image file as the canvas background

Parameters:

• Width/Height: Canvas dimensions in pixels
• Background Color: Hex color code (e.g., #FFFFFF)
• Image Path: Path to background image file (relative paths recommended)

Add Text

Add text overlays to your canvas with extensive customization options.

Input Methods:

• Manual: Single text element with full customization
• CSV File: Batch process multiple text elements from a CSV file

Text Properties:

• Position (X, Y coordinates)
• Font size and type selection
• Color (hex format)
• Rotation angle
• Opacity (0-255)

Font Selection:

• System Fonts: Choose from 58 comprehensive Windows fonts (Arial, Times New Roman, Segoe UI, etc.)
• Custom Fonts: Use custom font files or font family names
• Smart Fallback: Automatic fallback to sans-serif if font unavailable

CSV Format (Updated):

text,position_x,position_y,font_size,color,font_type,font_value,rotation,opacity
Hello World,100,50,36,#FF0000,system,Arial,0,255
Welcome,200,120,28,#0066CC,system,Microsoft YaHei,15,230
Custom Font,300,180,24,#009900,custom,/fonts/custom.ttf,0,255

Backward Compatibility: The node maintains compatibility with the old CSV format using font_name column.

Add Image

Overlay images onto your canvas with transformation options.

Parameters:

• Image Path: Path to overlay image file
• Position: X, Y coordinates for placement
• Scale: Scaling factor (1.0 = original size)
• Rotation: Rotation angle in degrees

🔄 Workflow Examples

Example 1: Text Badge Generator

[Manual Trigger] → [PicEdit: Create Canvas] → [PicEdit: Add Text] → [Save Binary]

1. Create a 400x200 canvas with blue background
2. Add white text "APPROVED" in the center
3. Output as PNG binary data

Example 2: Batch Certificate Generator

[CSV File] → [Split In Batches] → [PicEdit: Create Canvas] → [PicEdit: Add Text (CSV)] → [Email]

1. Load certificate template as canvas background
2. Process names from CSV file
3. Generate personalized certificates
4. Email each certificate

Example 3: Social Media Post

[HTTP Request: Image] → [PicEdit: Add Text] → [PicEdit: Add Image] → [Post to Social]

1. Fetch background image from URL
2. Add title text overlay
3. Add logo watermark
4. Post to social media platforms

⚙️ Configuration

Binary Data Fields

The node supports flexible binary data handling:

• Input Binary Field: Specify the field name containing input image data
• Output Field Name: Customize the output binary field name
• Format Options: PNG, JPEG, WebP with quality settings

File Path Security

For security, file paths are validated to prevent:

• Directory traversal attacks (../ patterns)
• Access to system directories
• Invalid or malicious paths

Best Practices:

• Use relative paths when possible
• Store assets in dedicated directories
• Avoid absolute system paths

Output Formats

Choose from multiple output formats:

• PNG: Lossless, supports transparency
• JPEG: Compressed, adjustable quality (1-100)
• WebP: Modern format with excellent compression

🛠️ Advanced Usage

Font Management

Enhanced Font Selection System (v0.1.4+)

The node now features a comprehensive font selection system:

Font Type Selection:

• System Fonts: Choose from 58 comprehensive Windows fonts including:

  • Basic Fonts: Arial, Times New Roman, Courier New, Verdana, Georgia, Tahoma, Impact
  • Modern Fonts: Segoe UI, Calibri, Cambria, Candara, Corbel, Constantia, Bahnschrift
  • Monospace Fonts: Consolas, Lucida Console, Cascadia Code, Cascadia Mono
  • Script/Decorative: Comic Sans MS, Trebuchet MS, Gabriola, Ink Free, Segoe Print, Segoe Script
  • International: Microsoft YaHei, SimHei, SimSun, DengXian, FangSong, KaiTi, Noto Sans SC
  • UI Fonts: Segoe UI, Microsoft Sans Serif, Leelawadee UI, Nirmala UI, Malgun Gothic
  • Symbol Fonts: Segoe UI Emoji, Segoe UI Symbol, Symbol, Webdings, Wingdings

• Custom Fonts: Use custom font files or font family names

  • Font file paths (./fonts/custom.ttf, ./fonts/custom.otf)
  • Font family names for web-safe fonts
  • Automatic fallback to system fonts if custom font unavailable

Font Rendering Features:

• Proper CSS font-family syntax with fallbacks
• SVG-based text rendering for precise typography
• Support for font weights and styles
• Unicode and emoji character support
• Cross-platform font compatibility

Smart Fallback System:

• Automatic fallback to sans-serif if specified font unavailable
• Font file validation and error handling
• Console warnings for missing custom fonts

Error Handling

Comprehensive error handling with detailed messages:

• File not found errors
• Invalid image format detection
• Path security violations
• Font loading failures

Performance Tips

• Use appropriate image sizes to avoid memory issues
• Optimize CSV files for batch processing
• Consider caching frequently used assets
• Use WebP format for smaller file sizes

🔧 Development

Building from Source

git clone https://github.com/hundred98/n8n-picEdit-node.git
cd n8n-picEdit-node
npm install
npm run build

Project Structure

n8n-nodes-picedit/
├── nodes/
│   └── picEdit/
│       ├── PicEdit.node.ts           # Main node implementation
│       ├── SharpImageProcessor.ts    # Sharp.js image processing engine
│       └── picEdit.svg               # Node icon
├── dist/                             # Compiled output
├── index.ts                          # Entry point
└── package.json

Technical Architecture

The node is built with modern web technologies:

• Sharp.js: High-performance image processing library
• SVG Composition: Text rendering using SVG for precise typography
• TypeScript: Type-safe development with full IDE support
• Zero Dependencies: No external tools or Python scripts required
• Memory Efficient: Optimized for large image processing workflows

Testing

npm run lint        # Code linting
npm run build       # Build project
npm run dev         # Development mode

🚨 Troubleshooting

Common Issues

"File not found" errors

• Check file paths are correct and accessible
• Use relative paths when possible
• Verify file permissions

"Invalid file path" errors

• Path contains security violations
• Use safe, relative paths
• Avoid system directories

Font rendering issues

• Specify full font file paths
• Use system-available fonts
• Check font file accessibility

Debug Information

The node provides detailed debug output including:

• Sharp.js processing status
• SVG text rendering information
• File path validations
• Image processing steps
• Font fallback mechanisms
• Error context and suggestions

📄 API Reference

Node Properties

Property	Type	Description
operation	string	Operation type: createCanvas, addText, addImage
outputFormat	string	Output format: png, jpeg, webp
quality	number	Image quality for lossy formats (1-100)
fieldName	string	Binary output field name

Input Data Structure

{
  json: {
    // Any JSON data
  },
  binary: {
    image: {
      data: "base64-encoded-image-data",
      mimeType: "image/png",
      fileName: "input.png"
    }
  }
}

Output Data Structure

{
  json: {
    success: true,
    message: "Canvas created successfully",
    fileInfo: {
      fileName: "generated-image.png",
      fileExtension: "png",
      mimeType: "image/png",
      fileSize: "15.6 KB"
    }
  },
  binary: {
    data: {
      data: "base64-encoded-result",
      mimeType: "image/png",
      fileName: "generated-image.png"
    }
  }
}

🤝 Contributing

Contributions are welcome! Please:

1. Fork the repository
2. Create a feature branch
3. Make your changes
4. Add tests if applicable
5. Submit a pull request

📝 Changelog

v0.1.4

• Enhanced Font Selection System: Comprehensive font type selection with 58 Windows fonts
• Font Type UI: Added hierarchical font selection menu (System Font / Custom Font)
• System Font Support: 58 comprehensive Windows fonts including Arial, Times New Roman, Segoe UI, Calibri, etc.
• Custom Font Support: Path-based custom font loading with fallback mechanisms
• Updated CSV Format: Added font_type and font_value columns for advanced font control
• Backward Compatibility: Maintains compatibility with old CSV format using font_name column
• Font Rendering Fix: Resolved font visibility issues with proper SVG font-family attributes
• Documentation: Added comprehensive font feature documentation and examples
• Sample Files: Added sample configuration files and system font detection script
• Code Cleanup: Removed test files and improved code organization

v0.1.0

• Initial release with Sharp.js architecture
• Canvas creation and text overlay features
• Image composition capabilities
• CSV batch processing
• Binary data integration
• Security enhancements
• Improved error handling
• Pure Node.js implementation (no Python dependencies)
• SVG-based text rendering for precise typography
• Cross-platform compatibility
• Unicode and emoji support
• High-performance image processing

📜 License

MIT License - see LICENSE file for details.
